The volume control technology is "AAVA". It is a volume adjustment technology using analog processing, and the input section is equipped with a total of 18 V-I conversion amplifiers. The input section is composed of four buffer amplifiers. The power supply section is independently configured and equipped with two high-efficiency toroidal transformers. In addition, four 10,000μF high-capacity, high-quality aluminum electrolytic capacitors for the filter are installed, and together with the transformer, it is a mono construction with independent left and right.
■Frequency response: 3 to 200,000Hz +0 (-3.0dB/BARANCED/LINE INPUT), 20Hz to 20kHzHz +0 (-3.0dB/BARANCED/LINE INPUT)
■Total harmonic distortion: 0.005%
■Power consumption: 34W
Size W (width): 477 mmH (height): 156 mmD (depth): 412 mm
Weight 23.7 kg
