Accuphase C-47 Phono Amplifier

Equipped with a balanced input terminal exclusively for MC cartridges, this phono equalizer amplifier is fully balanced from input to output. It is equipped with a head amplifier with a balanced input/output configuration designed specifically for MC/MM, using low-noise bipolar transistors for MC cartridges and low-noise JFETs for MM cartridges. This independent head amplifier output is switched and input to the equalizer amplifier, which equalizes the balanced signal as is. This enables fully balanced transmission from input to output.

■RIAA deviation: [MC] 10-20kHz ±0.3dB, [MM] 10-20kHz ±0.3dB ■Total harmonic distortion: 0.005%

■Gain: When GAIN button is OFF (normal): MC: 64dB, MM: 34dB When GAIN button is HIGH: MC: 70dB, MM: 40dB

■Input sensitivity (1kHz, rated output): 1.26mV at MC 64dB , MC70dB 0.63mV, MM34dB 40mV, MM40dB 20mV

■Maximum input voltage (1kHz, distortion rate 0.005%): MC64dB 5.7mV, MC70dB 2.9mV, MM34dB 180mV, MM40dB 90mV

■Maximum output level (distortion rate 0.01% 20-20,000Hz): BALANCED/LINE OUTPUT: 8.0V

■Input impedance: [MC switching] 10Ω, 30Ω, 100Ω, 300Ω, 1kΩ [MM switching] 1kΩ, 47kΩ, 100kΩ

■Rated output/output impedance: BALANCED/LINE OUTPUT 2V 50Ω

■Minimum load impedance: BALANCED/LINE OUTPUT 10kΩ

■Input terminals: 3 systems

■Output terminals: RCA1, XLR1

■Subsonic filter: -12bB/Octave, 10Hz

■Crosstalk: -90dB or less (10kHz)

■Power consumption: 21W

Accessories: Manual, power cable, power cable, original box included

Size W(width): 465 mmH(height): 114 mmD(depth): 407 mm

Weight 14.8 kg
