Accuphase P-4600 Power Amplifier Class AB

The P-4600 follows the technology of the P-7500 and incorporates the latest technology, and the high-power design unique to Accuphase Class AB power amplifiers has achieved a significant increase in maximum output, making it a high-performance, high-output power amplifier. The "low noise" achieved by the polished, ideal balanced circuit (instrumentation amplifier method) and the "high output" achieved by the powerful power stage supported by an unshakable power supply unit provide ample driving force. The impressive aluminum die-cast heat sink is integrated with the aluminum front panel and chassis to achieve a robust structure. The top plate uses a luxurious hairline-finished aluminum panel, and combined with the traditional champagne gold front panel, it exudes a style that goes beyond its class. Size W (width): 465 mmH (height): 190 mmD (depth): 427 mm

Weight 30 kg

■Rated output: 150W+150W (8Ω), 300W+300W (4Ω), 450W+450W (2Ω)

■Input: RCA1, XLR1　■Speaker output: 2 systems　■Damping factor: 800 or more

■Frequency response: 20-20kHz (+0, -0.2dB) at rated output, 0.5-160kHz (+0, -3.0dB) at 1W output

■Total harmonic distortion (20-20kHz) Normal/bi-amp connection 2Ω load 0.05%, 4-16Ω load 0.03%, bridge connection 4-16Ω load 0.05%

■IM distortion rate: 0.01%

■Load impedance: Normal/Bi-amp connection 4-16Ω (2-16Ω possible for music signals only), Bridge connection 8-16Ω (4-16Ω possible for music signals only)

■S/N ratio: 125dB (GAIN switch MAX), 130dB (GAIN switch -12dB)

■Power supply: AC100V 50/60Hz

■Power consumption: 94W (no input), 440W (Electrical Appliance and Material Safety Act), 565W (8Ω load rated output)

■Standby 0.3W
