Accuphase PS-1200 Clean Power Supply
Accuphase PS-1200 Clean Power Supply
Regular price
$2,416.80 USD
Regular price
Sale price
$2,416.80 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
| Condition: Used | Compatible Brand: Universal |
| Size: 475 x 242 x 508 mm | Color: Gold |
| Compatible Model: Universal | MPN: PS-1200 |
| Weight: 37.2 kg | Compatible Product Line: Universal |
| California Prop 65 Warning: N/A | Brand: Accuphase |
| Type: Power Conditioner | Unit Type: Unit |
| Capacity: 1200VA | Model: PS-1200 |
| Features: Accuphase | Country/Region of Manufacture: Japan |
| Unit Quantity: 1 |
Description
The PS-1200 is designed to add or subtract the input AC power using a control circuit to correct it, then output it as AC. The main energy is the input AC power itself, and the only loss is the power for waveform correction, so it is more efficient than conventional AC constant voltage devices. It also generates less heat and is lighter.
The power supply frequency is input synchronous, so there is no need for an internal oscillator, and no high-frequency noise is generated from inside.
Rated output capacity 1,200VA (continuous output)
Rated output voltage AC100V±2V
Rated output current 12A
Output frequency 50Hz/60Hz (synchronized with input frequency)
Instantaneous current supply capacity 140A
Output waveform total harmonic distortion 0.3% or less
Input voltage range AC90V-110V
Input frequency 50Hz/60Hz
Input capacity 1,500VA (at rated output)
Power consumption at no load 60W
Cooling method Natural air cooling
Meter Wattage: 0-1,200W
Voltage input/output: AC90-110V
Red range of scale: AC100V±5V
Distortion input/output: 0-6%
Maximum external dimensions Width 475 x Height 242 x Depth 508mm
Weight 37.2kg
