Number of installed power amplifiers: 11ch
Rated output
(8Ω, 20Hz to 20kHz, THD 0.05%, 2ch drive) 140W+140W
Practical maximum output
(JEITA: 6Ω, 1kHz, THD 10%, 1ch drive) 250W
Compatible impedance 4 to 16Ω
Frequency characteristics 10Hz to 100kHz (+1-3dB, in direct mode)
S/N ratio 102dB (IHF-A, in direct mode)
Distortion rate 0.005% (20Hz to 20kHz, in direct mode)
Wireless LAN network type (wireless LAN standard): IEEE 802.11a/b/g/n compliant (Wi-Fi® compliant)
Security: WEP 64bit, WEP 128bit, WPA/WPA2-PSK (AES), WPA/WPA2-PSK (TKIP)
Radio frequency: 2.4GHz / 5GHz
Bluetooth version:4.2
Supported profiles: Receiving: A2DP 1.2, AVRCP 1.5, Transmitting: A2DP
Compatible codec: SBC
Frequency band/transmission output/communication distance: 2.4GHz band/Class 1/approx. 30m (line-of-sight distance)
HDMI terminal input x 8 (front x 1): *8K compatible input x 1 (HDMI 7)
Output x 3 (Monitor x 2, Zone 2 x 1): *8K compatible output x 2 (Monitor 1/2)
Analog video input/output terminal Composite input x 4, component input x 2,
Composite output x 2 (monitor x 1, zone 2 x 1), component output x 1
Audio input/output terminals Analog audio input x 7, PHONO input x 1, optical digital input x 2,
Coaxial digital input x 2, 13.2ch pre-out x 1, zone pre-out x 2, headphone output x 1 (front)
Other input/output terminals Network x 1, USB-A x 1 (front), setup microphone input x 1 (front),
RS-232C x 1, DC trigger output x 2, remote control (IR) input/output x 1 each
External dimensions
(Including feet, terminals, knobs, and antenna) W434 x H235 x D389mm (with antenna up)
W434 × H167 × D389mm (when antenna is laid down)
Mass 14.8kg
Power supply AC 100V, 50/60Hz
Power consumption 750W
Standby power 0.1W (normal standby) 0.5W (CEC standby)
Accessories: Easy start guide, remote control, 2 AA batteries, setup microphone,
Microphone stand, Wi-Fi/Bluetooth antenna x 2, cable label, power cord
