Denon AVR-X1700H 7.2ch 8K AV Surround Receiver Black UltraHD HDR10+ eARC 100V

Number of installed power amplifiers: 7ch

Rated output (8Ω, 20Hz to 20kHz, THD 0.08%, 2ch drive): 80W+80W

Practical maximum output (JEITA: 6Ω, 1kHz, THD 10%, 1ch drive): 175W

Compatible impedance: 4-16Ω

Frequency characteristics: 10Hz to 100kHz (+1,-3dB, in direct mode)

S/N ratio: 98dB (IHF-A, in direct mode)

[Wireless LAN]

Network type (wireless LAN standard): IEEE 802.11a/b/g/n/ac compliant (Wi-Fi compliant)

Security: WEP 64bit, WEP 128bit, WPA/WPA2-PSK (AES), WPA/WPA2-PSK (TKIP), WPA3-SAE (AES)

Radio frequency: 2.4GHz/5GHz

[Bluetooth]

Version: 4.2

Supported profiles: (receive) A2DP1.3.2, AVRCP1.6.2/(send) A2DP1.3.2

Compatible codec: SBC

Frequency band/transmission output/communication distance: 2.4GHz band/Class1/approx. 30m (line-of-sight distance)

[HDMI and other input/output terminals]

Input x 6 *HDMI4/5/6: 8K60AB/4K120AB (maximum 40Gbps) compatible

Output x 1 *8K60AB/4K120AB (maximum 40Gbps) compatible, eARC compatible

Analog video input/output terminal: Composite input x 2, composite output x 1

Audio input/output terminals: Analog audio input x 2, PHONO input (MM) x 1, optical digital input x 2, subwoofer pre-out x 2, headphone output x 1 (front)

Other input/output terminals: Network x 1, USB-A x 1 (front), FM antenna terminal x 1, AM antenna terminal x 1, setup microphone input x 1 (front)

【others】

Tuner reception frequency band: (FM) 76.0-95.0MHz, (AM) 522-1629kHz

External dimensions (including foot, terminal, knob, antenna)

When the antenna is erected: W434 x H215 x D339mm

When the antenna is laid down: W434 x H151 x D339mm

Mass: 8.6kg

Power supply: AC100V, 50/60Hz

Power consumption: 440W

Standby power: 0.1W (normal standby), 0.5W (CEC standby)

Accessories: Easy start guide, warranty card, remote control, AAA batteries x 2, setup microphone, microphone stand, FM indoor antenna, AM loop antenna, cable label
