Denon AVR-X3800H 9.4 Channel AV Surround Receiver 8K Ultra HD HDR10+ 100V NEW

・9ch discrete power amplifier with maximum output of 215W (6Ω, 1kHz, THD 10%, 1ch drive, JEITA)

・Compatible with 11.4ch processing, equipped with 11.4ch pre-out, also equipped with preamp mode

・Compatible with Dolby Atmos, DTS:X, IMAX Enhanced, Auro-3D, MPEG-4 AAC

・Supports MPEG-H 3D Audio (360 Reality Audio)

Video - Compatible with 8K Ultra HD/HDR10+/eARC

・6 input/2 output HDMI terminal supports 8K/60Hz and 4K/120Hz (up to 40Gbps)

・Supports the latest HDMI features that revolutionize the video experience

(HDR10+/Dynamic HDR/HDR10/Dolby Vision/HLG/BT.2020/VRR/QFT/ALLM/eARC)

Network - Powered by HEOS

・Compatible with a wide range of music streaming services (Amazon Music HD/AWA/Spotify/SoundCloud)

・5.6 MHz DSD & high resolution sound source compatible (music server & USB memory)

・Internet radio (TuneIn), AirPlay 2, Bluetooth (transmission/reception), Amazon Alexa voice control compatible

Usability - Easy to use various functions

・High resolution, easy to read, and sophisticated design HD GUI

●Number of installed power amplifiers: 9ch

●Rated output (8Ω, 20Hz to 20kHz, THD 0.08%, 2ch drive): 105W + 105W

●Maximum practical output (JEITA: 6Ω, 1kHz, THD 10%, 1ch drive): 215W

●Applicable impedance: 4 to 16Ω

●Frequency characteristics: 10Hz to 100kHz (+1, -3dB, in direct mode)

●S/N ratio: 100dB (IHF-A, in direct mode)

●Wireless LAN

・Network type (wireless LAN standard): IEEE 802.11a/b/g/n/ac compliant (Wi-Fi compliant)

・Security: WEP 64bit, WEP 128bit, WPA/WPA2-PSK (AES), WPA/WPA2-PSK (TKIP)

・Radio frequency: 2.4GHz/5GHz

●Bluetooth

・Version: 4.2

・Supported profiles

Reception: A2DP 1.2, AVRCP 1.5

Transmission: A2DP 1.2

・Supported codec SBC

・Frequency band/transmission output/communication distance: 2.4GHz band/Class 1/approx. 30m (line-of-sight distance)

●HDMI terminal

・Input x 6 *8K60AB/4K120AB (maximum 40Gbps) compatible

・Monitor output x 2 *8K60AB/4K120AB (maximum 40Gbps) compatible, eARC/ARC compatible (MONITOR 1)

・Zone 2 output x 1 *4K60Hz compatible

●Audio input/output terminals: Analog audio input x 5, PHONO input (MM) x 1, optical digital input x 2, coaxial digital input x 2, 11.4ch pre-out x 1, zone pre-out x 1, headphone output x 1 (front)

●Other input/output terminals: Network x 1, USB-A x 1 (front), FM antenna terminal x 1, AM antenna terminal x 1, setup microphone input x 1 (front), RS-232C x 1, DC trigger output x1, remote control (IR) input/output x1 each

●Tuner reception frequency band

・FM: 76.0 ~ 95.0MHz

・AM: 522 to 1629kHz

●External dimensions (including foot, terminal, knob, and antenna)

・When the antenna is erected W434 × H237 × D389mm

・When the antenna is laid down W434 × H167 × D389mm

●Mass: 12.5kg

●Power supply: AC 100V, 50/60Hz

●Power consumption: 660W

●Standby power

・0.1W (Network control, HDMI pass-through off)

・0.5W (CEC standby)

●Accessories: Easy start guide, remote control, AAA batteries x 2, setup microphone, microphone stand, FM indoor antenna, AM loop antenna, Wi-Fi/Bluetooth antenna x 2, cable label, power cord
