■ Power amplifier section
Rated output 80 W + 80 W (8Ω, 20 Hz to 20 kHz, THD 0.07%)
160W + 160W (4Ω, 1kHz, THD 0.7%)
Total harmonic distortion rate 0.01% (at rated output, -3 dB), load 8Ω, 1 kHz
Output terminal Speaker A or B: Load 4 to 16Ω
Speaker A + B: Load 8-16Ω
Input sensitivity / input impedance EXT. PRE: 0.9 V / 47 kΩ
Gain value: 29 dB
■ Preamp section
Input sensitivity / input impedance PHONO (MM): 2.5 mV / 47 kΩ
PHONO(MC): 200μV / 100Ω
CD, NETWORK, AUX, RECORDER:
135 mV / 47 kΩ (source direct off),
135 mV / 23 kΩ (source direct on)
RIAA deviation PHONO: ± 0.5 dB (20 Hz to 20 kHz)
Maximum input PHONO (MM): 130 mV / 1 kHz PHONO (MC): 10 mV / 1 kHz
■ Input/output terminals
Analog audio input terminals Unbalanced input x 4, PHONO (MM/MC) input x 1, EXT. PRE input x 1
Analog audio output terminal Unbalanced output (RECORDER) x 1
Digital audio input terminal USB-B input x 1, coaxial digital input x 2, optical digital input x 2
Others IR control input/output x 1
■ Comprehensive characteristics
S/N ratio (A network) PHONO (MM): 89 dB (input terminal shorted, input signal 5 mV)
PHONO (MC): 74 dB (input terminal shorted, input signal 0.5 mV)
CD, NETWORK, AUX, RECORDER: 110 dB (input terminal shorted)
Frequency response 5 Hz to 100 kHz (0 to -3 dB)
Tone control BASS: 100 Hz ±8 dB
TREBLE: 10 kHz ±8 dB
■ Overall
External dimensions (W x H x D) 434 x 182 x 431 mm
Mass 25.0 kg
Power consumption 310 W (according to the Electrical Appliance and Material Safety Law)
Standby power 0.2W
Accessories Easy start guide, instruction manual, remote control, AAA batteries x 2, power cord
