DENON PMA-SX11-SP Pre-Main Amplifier PMA SX11 DAC compatible Silver 100V NEW
DENON PMA-SX11-SP Pre-Main Amplifier PMA SX11 DAC compatible Silver 100V NEW
Regular price
$3,190.00 USD
Regular price
Sale price
$3,190.00 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
| Condition: New | Brand: Denon |
| Type: Pre-Amp/Processor | Unit Type: Unit |
| Color: Silver | Model: PMA-SX11 |
| MPN: PMA-SX11 | Country/Region of Manufacture: Unknown |
| Unit Quantity: 1 | UPC: 4951035056417 |
Description
Power amplifier section
Rated output: 120 W + 120 W (8Ω, 20 Hz to 20 kHz, THD 0.1%)
240W + 240W (4Ω, 1kHz, THD 0.7%)
Total harmonic distortion: 0.01% (at rated output, -3 dB), load 8Ω, 1 kHz
Output terminal: Speaker load: 4 to 16Ω
Input sensitivity / input impedance EXT. PRE: 1.1 V / 23 kΩ
Gain value: 29 dB
preamplifier
Recording output terminal 150 mV
Input Sensitivity / Input Impedance PHONO (MM): 2.5 mV / 47 kΩ
PHONO (MC): 200 μV / 100 Ω (High), 200 μV / 50 Ω (Low)
CD, NETWORK, TUNER, AUX, RECORDER: 165 mV / 25 kΩ
BALANCED: 165 mV / 100 kΩ
RIAA deviation: PHONO (MM / MC): ± 0.5 dB (20 Hz to 20 kHz)
Maximum input: PHONO (MM): 130 mV / 1 kHz PHONO (MC): 10 mV / 1 kHz
Overall characteristics
S/N ratio (IHF A network, 8Ω load):
PHONO (MM): 82 dB (input terminal shorted, input signal 5 mV)
PHONO (MC): 70 dB (input terminal shorted, input signal 0.5 mV)
CD, NETWORK, TUNER, AUX, RECORDER: 108 dB (input terminal shorted)
Frequency response: 5 Hz to 100 kHz (0 to -3 dB)
comprehensive
External dimensions (W x H x D): 435 x 181 x 506 mm
Mass: 27.4 kg
Power consumption: 380 W (according to the Electrical Appliance and Material Safety Law)
Standby power: 0.1 W / 0.2 W (when auto standby mode is on / off)
Accessories: Easy start guide, instruction manual, remote control, AAA batteries x 2, power cord
