The length of the channel fader has been revamped from 45mm on the "DJM-V10" to 60mm, and the existing 3 types of curve presets have been added with 1 new type of curve preset that is ideal for volume control of the 60mm channel fader.
In DJ performances, it is required to adjust the volume of songs more smoothly according to the atmosphere of the audience, and to mix accurately and precisely. With the DJM-V10-LF, by eliminating the crossfader from the "DJM-V10" and installing a 60mm channel fader, it is now possible to more accurately control the volume of each channel.
Other features and specifications are the same as the DJM-V10, which has been popular among many DJs since its release in early 2020. It enables creative and intuitive performances by mixing sound sources that transcend generations and genres and by mixing sound sources with different mastering conditions more naturally.
■ Main specifications of DJM-V10-LF
◁ECompatible software: rekordbox, Serato DJ Pro, TRAKTOR PRO 3, ShowKontrol, PRO DJ LINK BRIDGE
◎Frequency characteristics: 20Hz - 40kHz (LINE)
◎S/N ratio: 116 dB (USB, DIGITAL IN), 105 dB (LINE), 88 dB (PHONO), 79 dB (MIC1,2)
◎Total harmonic distortion: 0.005% (LINE-MASTER1)
◁EInput:
・DIGITAL x 6 (Coaxial)
・LINE x 6 (RCA)
・PHONO x 4 (RCA)
・RETURN x 3 (1/4-inch TS jack)
・MIC x 2 (XLR & 1/4-inch TRS Jack, 1/4-inch TRS jack)
◁EOutput:
・MASTER x 2 (XLR, RCA)
・AES/EBU DIGITAL MASTER x 1 (XLR)
・BOOTH x 1 (1/4-inch TRS jack)
・SEND x 3 (1/4-inch TS jack)
・HEADPHONE MONITOR x 4 (1/4-inch stereo jack x 2, 3.5-mm stereo mini jack x 2)
・REC x 1 (RCA)
◎USB: USB (Type A) x 1, USB (Type B) x 2
◎Others: LINK (LAN) x 1, MIDI (5-pin DIN) x 1
◁EExternal dimensions: 437.6 x 467.0 x 107.9 mm (width x depth x height)
◎Mass: 12.1 kg
◁EAccessories: Power cord, quick start guide (Japanese)
