KAOSS Pad effects: 128 types
Mic-specific effects: tone, delay, reverb
Maximum number of projects: 100
Trigger pad: 16 (velocity compatible) x 8 banks
Hot cue: Up to 12 locations (per trigger pad)
Simultaneous views: 16
Audio: Linear PCM (48kHz/16bit)
Recording functions: sampling, resampling (*up to 30 minutes), live recording (*up to 100 minutes)
Audio input terminal:
LINE/PHONO IN terminal: RCA pin jack (LINE/PHONO selection)
PHONO GAIN switch (LO/HI)
MIC IN terminal: Standard phone jack (φ6.3mm, monaural TS)
*For dynamic microphone only
AUX IN terminal: Stereo mini jack (φ3.5mm) *Mix directly to LINE OUT
Audio output terminal:
LINE OUT jack: RCA pin jack
Headphone jack: Standard stereo phone jack (φ6.3mm)
Controller input: Foot switch terminal: Standard phone jack (φ6.3mm, TS) *Connect PS-1 or PS-3 (sold separately)
USB terminal: microB (MIDI, audio (IN x 2ch, OUT x 34ch (48kHz/16bit, KORG KaossReplay Audio Driver must be installed in the Windows environment)
MIDI terminal: IN/OUT (DIN 5pin) MIDI function is exclusively for USB terminal (IN x 1 port, OUT x 1 port)
External storage: microSD card, microSDHC card (up to 32GB) *Class 10 or higher, UHS-I (U1) recommended (However, operation with all cards is not guaranteed.)
External dimensions: 185 (W) x 284 (D) x 56 (H) mm
Mass: 2.0kg *Excluding microSD card and AC adapter
Power supply: DC 5V/3A
Accessories: Quick start guide, AC adapter, USB cable (TypeA to microB, 1m), microSDHC card (inserted into the microSD card slot of the main unit at the time of shipment.)
