Correspondence disc 2 channel CD
Correspondence sampling frequency USB input (PCM): 44.1kHz, 48kHz, 88.2kHz, 96kHz
176.4kHz, 192kHz, 352.8kHz, 384kHz (16, 24, 32bit)
USB input (DSD): 2.8MHz, 5.6MHz, 11.2MHz (1bit)
COAX/OPT input: 44.1kHz, 48kHz, 88.2kHz, 96kHz
176.4kHz, 192kHz (16, 20, 24bit)
Analog Output Voltage/Impedance Unbalanced 2.4V/300Ω, Balanced 2.4V/600Ω
1.7V for DSD
Frequency response CD 5Hz - 20kHz (+0, -1.0dB)
COAX/OPT 5Hz - 47kHz (+0, -3.0dB)
USB 5Hz to 47kHz (+0, -3.0dB)
Total harmonic distortion CD 0.003%, COAX/OPT 0.002%, USB 0.002%
S/N ratio (IHF-A) CD 101dB, COAX/OPT 114dB, USB 113dB
D/A converter TI PCM1795 (monaural mode) x 2
Power supply voltage AC100V (50/60Hz)
Power consumption 16W (according to the provisions of the Electrical Appliance and Material Safety Law)
External dimensions 440 (width) x 133 (height) x 410 (depth) mm
Depth includes front knob 2mm, rear terminal 8mm
Mass 13.2kg (main unit), 17.6kg (standard packaging)
Accessories Remote control (RD-28)
Power cable (JPA-10000i: with polarity mark)
* By pressing the output phase inversion switch, it becomes INVERT, and balance output terminal No. 2 can be switched to HOT and No. 3 to COLD.
*Please download and use the LUXMAN Audio Player (Windows 10/macOS 10.15 compatible) and Windows driver software for free from our website.
*Apple, Mac, Mac OS, OS X, macOS, and Macintosh are trademarks of Apple Inc. registered in the United States and other countries.
*Microsoft and Windows are registered trademarks of Microsoft Corporation in the United States and other countries.
*Sound Wave Logo is a registered trade mark of MQA Limited.(c)2018
*MQA is a registered trade mark of MQA Limited.(c)2018
*MQA-CD is a registered trade mark of MQA Limited.(c)2017
*The power cable included with this product has been changed from JPA-10000 to JPA-10000i. (Sequentially from production in 2020)
