LUXMAN D-08u SACD/CD Player

SACD/CD player with USB DAC. The USB DAC section supports 32bit/384kHz PCM and 2.8/5.6MHz DSD. The DAC is equipped with TI's "PCM1792A" in a dual mono configuration, and also uses TI's DSP "TAS3152" which upsamples PCM signals to up to 384kHz. The PCM signal can be switched between three types of digital filters by the 32bit DSP, and the DSD signal can be switched between two types of sound quality by the analog FIR filter built into the DAC chip. The USB supports low jitter transmission by asynchronous communication. The player software "LUXMAN Audio Player" for Windows and Macintosh is included, and it supports not only DSD and FLAC, but also Apple Lossless and AIFF. The disk drive mechanism is the company's original "LxDTM". The "left side mechanism layout" is placed on the left side, taking into consideration the ideal signal flow, vibration path, weight balance, etc. ■Supported discs: 2-channel SACD, CD ■Digital inputs: 1 USB, 1 COAX, 2 OPT ■Digital outputs: 1 COAX, 1 OPT ■Supported sampling frequencies: USB input (PCM): 32k, 44.1k, 48k, 88.2k, 96k, 176.4k, 192k, 352.8k, 384kHz (16, 24, 32bit) ■USB input (DSD): 2.82M, 5.64MHz (1bit) ■COAX/OPT input: 32k, 44.1k, 48k, 88.2k, 96k, 176.4k, 192kHz (16, 20, 24bit) ■Analog outputs: 1 unbalanced, 1 balanced ■Analog output voltage/impedance 2.5V/300Ω (unbalanced), 600Ω (balanced) ■Frequency characteristics: CD 5Hz to 20kHz (+0, -0.5dB), SACD 5Hz to 50kHz (+0, -3.0dB), USB 2Hz to 50kHz (+0, -3.0dB) ■Total harmonic distortion/S/N ratio (IHF-A) CD 0.0015%, SACD 0.0011%, USB 0.0009%/CD 121dB, SACD 105dB, USB 119dB■Power consumption: 36W (Electrical Appliance and Material Safety Act), 1W (standby)■Accessories: Remote control (RD-21), power cable (JPA-15000: with polarity mark), installation software CD

Size W (width): 440 mmH (height): 154 mmD (depth): 413 mm

Weight 22.5 kg
