An analog record that records the vibrations and resonance of music without interruption. It can be said that the joy of analog playback is to revive the story of that continuous sound. The phono equalizer amplifier EQ-500 uses vacuum tubes in all stages as amplification elements in order to reproduce the breath of music in a rich and colorful manner. The front panel has a number of detailed adjustment and switching functions that allow you to fully enjoy the real pleasure of analog playback, pursuing mechanical presence and functional beauty. Introducing Luxman's proud product, the EQ-500, which proposes a menu that allows you to fully enjoy analog playback and allows you to freely approach your own ideal sound that is still in your memory.
〇 Circuit method SRPP, final stage cathode follower, non-feedback CR type equalizer (RIAA)
〇 Vacuum tubes used: ECC83 x 4, ECC82 x 2, EZ81 x 1
〇 Input sensitivity (1kHz, gain switching 36dB) MM 4mV, MC high 0.44m V, MC low 0.18mV
〇 Input impedance MM 30kΩ to 100kΩ (variable), MC high 40Ω, MC low 2.5Ω
〇 Rated output / Output impedance 250mV / 850Ω
〇 Gain (at 1kHz, gain switching 36dB) MM 36dB, MC high 55dB, MC low 63dB
〇 Maximum allowable input (1kHz) MM 300mV, MC high 34mV, MC low 13mV
〇 RIAA deviation MM / MC high / MC low 20Hz - 20kHz (±0.3dB)
〇 Total harmonic distortion rate 0.07%
〇 S/N ratio (IHF-A) MM 76dB, MC high 75dB, MC low 74dB
〇 Channel separation (10kHz) 65dB
〇 Input unbalanced 3 systems
〇 Output: 2 unbalanced systems, 1 balanced system
〇 Power supply voltage AC100V (50/60Hz)
〇 Power consumption 47W (according to the Electrical Appliance and Material Safety Law)
〇 External dimensions 440 (width) x 92 (height) x 397 (depth) mm
〇 Depth includes front knob 5mm and rear terminal 12mm
〇 Weight 12.5kg (main unit), 15.2kg (standard packaging)
〇 Accessories Power cable (JPA-10000i: with polarity mark)
