LUXMAN LTA-710 Universal Static Balance Tonearm 10 inch NEW

LUXMAN LTA-710 Universal Static Balance Tonearm 10 inch NEW

Regular price $2,871.36 USD
Regular price Sale price $2,871.36 USD
Sale Sold out
Shipping calculated at checkout.
Condition: New Brand: Luxman
Compatible Brand: Universal Type: Tonearm
Unit Type: Unit Color: Silver
Features: LUXMAN,LTA-710,Tonearm,Static Balance Country/Region of Manufacture: Japan
Unit Quantity: 1

Description

The universal tone arm LTA-710 is a 10-inch tone arm with knife-edge bearings, developed jointly with SAEC as a derivative model of the PD-191A. This long-awaited standalone model has now been commercialized. As an option, a dedicated arm base is also available that allows this arm to be attached to the PD-171AL and PD-171A, which have been on the market for approximately eight years since 2013.

Features

- A completely new universal type static balance tonearm jointly developed with SAEC

- The bearings have a knife-edge structure with excellent initial sensitivity

- The effective length is 10 inches, which reduces tracking errors and improves damping against surface vibration

- The included headshell with the LUXMAN logo is equipped with lead wires made of high-purity conductor 7N-Class D.U.C.C. (99.99998% or more copper) that uses copper of the world's highest purity level and has optimally controlled crystal orientation

- The optional OPPD-AB7 arm base for mounting on PD-171A/PD-171AL/PD-191A/PD-191AL is available

- A convenient positioning gauge is included when mounting on analog players from other companies

* SAEC is a brand of Saeku Commerce Co., Ltd., which has a history of over 40 years in the world of analog audio.

* D.U.C.C. is a registered trademark of Mitsubishi Materials Corporation.

Specifications
Type/Bearing: Static balance, S-shaped/knife edge
Effective length: 256mm
Tracking error angle: +1.07° to -1.52°
Overhang: 16mm
Applicable cartridge weight: 4 to 11g (17 to 24g including included head shell)
Height adjustment range: 22mm (from center of arm pipe to top surface of top panel)
Anti-skating: 0 to 4g
Total length: 278.7mm
Weight: 713g (including counterweight, anti-skating weight, and mounting base)
Accessories: Head shell, phono cable, counterweight, mounting base, mounting base mounting screws, anti-skating weight, overhang gauge, tone arm mounting gauge, arm lifter adjustment wrench, tone arm adjustment wrench, mounting base mounting wrench
