LUXMAN M-800A Pure-CLASS-A Stereo Power Amplifier IN STOCK

LUXMAN M-800A Pure-CLASS-A Stereo Power Amplifier IN STOCK

Regular price $4,900.00 USD
Regular price Sale price $4,900.00 USD
Sale Sold out
Shipping calculated at checkout.
Condition: Used Brand: Luxman
Type: Power Amplifier Unit Type: Unit
Color: Silver Model: M-800A
Country/Region of Manufacture: Japan Unit Quantity: 1
Power: 60 W Amplifier Class: A

LUXMAN M-800A Pure-CLASS-A Stereo Power Amplifier AC100V From Japan

Description

Realizes high-density music playback Pure class A operation system 60W rated output
Instantaneous maximum 480W (1Ω) that follows various speaker loads
The dynamic power that linearly follows all load conditions is the power amplifier inherited from the B-1000f.
It is a gene as. For M-800A, rated output is 60W + 60W when loaded with 8Ω, instantaneous maximum when loaded with 1Ω
Achieves power linearity of 480W + 480W. Furthermore, with BTL connection, 240W at 8Ω load,
It can also be used as a monaural amplifier with a high instantaneous output of up to 960W when loaded with 2Ω.

spec
Continuous effective output 60W + 60W (8Ω) / stereo
120W + 120W (4Ω) / Stereo
240W (8Ω) / at BTL
Maximum output 480W + 480W (1Ω) / stereo
960W (2Ω) / at BTL
Input sensitivity 773mV/60W (8Ω), GAIN 29dB
Input impedance unbalanced / 51kΩ, balanced / 67kΩ
Total harmonic distortion
0.009% or less (1kHz, 60W / 8Ω)
0.1% or less (20Hz to 20kHz, 60W / 8Ω)
Frequency characteristics 20Hz to 20kHz (+0, -0.2dB)
DC to 130kHz (+0, -3.0dB)
S/N ratio 117dB (IHF-A)
Damping factor 700/8Ω
Attached equipment
front panel
: Operation switch, operation indicator, standby indicator, input selection switch, balance indicator, BTL indicator, level meter, meter display switch
rear panel
: Main power switch, BTL switch, input terminal (1 system each for unbalanced and balanced), speaker output (1 system), signal ground terminal, remote input terminal, line phase sensor, AC inlet
Total harmonic distortion
0.009% or less (1kHz, 60W / 8Ω)
0.1% or less (20Hz to 20kHz, 60W / 8Ω)
Frequency characteristics 20Hz to 20kHz (+0, -0.2dB)
DC to 130kHz (+0, -3.0dB)
S/N ratio 117dB (IHF-A)
Damping factor 700/8Ω
Attached equipment
front panel
: Operation switch, operation indicator, standby indicator, input selection switch, balance indicator, BTL indicator, level meter, meter display switch
rear panel
: Main power switch, BTL switch, input terminal (1 system each for unbalanced and balanced), speaker output (1 system), signal ground terminal, remote input terminal, line phase sensor, AC inlet
Accessories Instructions Only those shown in the photo.
Power consumption 492W (according to the provisions of the Electrical Appliance and Material Safety Law)
396W (no signal), 0.9W (standby)
External dimensions 440 (width) x 224 (height) x 485 (depth) mm
Weight 48.5kg
