LUXMAN MQ-300 Stereo Power Amplifier Takatsuki TA-300B Tube

This is a single vacuum tube stereo power amplifier with 8W + 8W output, equipped with the TA-300B directly heated triode. It has a simple configuration of a voltage amplification block with two parallel connected 6SN7GTBs and a single 300B power block connected with Luxman's original oil capacitor, and by making the whole unit non-feedback, it achieves a natural and musical tone that makes the most of the characteristics of the 300B rather than numerically high output or high-fidelity performance. It also features a top panel made of 12mm thick aluminum material, large gradation cast iron insulator legs that support the entire chassis, a large-capacity output transformer made of Orient core material with a design reminiscent of the old OY transformer, and a choke coil made of Finemet core material. ■Continuous output: 8W+8W (4, 8, 16Ω)

■Input sensitivity / Input impedance: 490mV (8W) / 240kΩ ■Frequency response: 20Hz to 20kHz (+0.3, -1.5dB), 10Hz to 30kHz (+0.3, -3.0dB)

■Total harmonic distortion / S/N ratio (IHF-A): 1% or less (1kHz/8Ω/1W) / 105dB

■Input / Output: 1 line / 1 large speaker terminal (4, 8, 16Ω independent)

■Circuit type: Driver: Parallel connection 2-stage amplification, Output: Single configuration, Overall: Non-feedback amplification

■Vacuum tubes used: 5AR4 (SOVTEK) x 2, 6SN7GTB (TUNG-SOL) x 4, TA-300B (Takatsuki Electric Industry) x 2

■Accessories: Instruction manual, power cable (non-genuine)

■Power consumption: 160W (Electrical Appliance and Material Safety Act), 160W (no signal)

Dimensions W (width): 460 mm H (height): 237 mm D (depth): 340 mm

Weight 29 kg
