LUXMAN SQ-N150 Tube Integrated Amplifier audio music Preamps 100V NEW
LUXMAN SQ-N150 Tube Integrated Amplifier audio music Preamps 100V NEW
Regular price
$2,290.00 USD
Regular price
Sale price
$2,290.00 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
Condition: New | Supported Modes: NA |
Receiver Combo Features: NA | Color: NA |
MPN: SQ-N150 | Surround Sound Formats: NA |
Audio Outputs: NA | Number of Outputs: NA |
Brand: Luxman | Type: Tube Amplifier |
Audio Inputs: NA | Number of Channels: NA |
Number of Inputs: NA | Model: SQ-N150 |
Features: NA | Power: NA |
UPC: 4958136000578 |
Description
Rated output 10W+10W(6Ω)
Input sensitivity/input impedance PHONO(MM):3.0mV/47kΩ
PHONO(MC):0.33mV/100Ω
LINE:180mV/47kΩ
Frequency characteristics PHONO: 20Hz to 20kHz (within ±0.5dB)
LINE: 20Hz to 80kHz (within -3.0dB)
Total harmonic distortion rate 1% or less (1kHz, 10W/6Ω)
S/N ratio (IHF-A) PHONO (MM): 84dB or more
PHONO(MC):64dB or more
LINE:95dB or more
Circuit method Driver: P-K split phase inversion circuit
Output: Pentode connection
Vacuum tubes used: ECC83 x 2
EL84 x 4 pieces
Power-supply voltage/
Power consumption AC100V(50/60Hz) /
80W (according to the provisions of the Electrical Appliance and Material Safety Law)
External dimensions 297 (width) x 188 (height) x 251 (depth) mm
(Depth includes front knob 20mm and rear terminal 21mm)
Mass: 12.4kg (main unit), 14.8kg (standard packaging)
Accessories Power cable (JPA-10000i: with polarity mark)
speaker terminal
Compatible Y lug terminal dimensions
Part a width: 14.5mm or less
Part b width: 7.5mm or more
*Optional remote control RA-25
