Marantz AV8805A 13.2Ch 8K UHD Pre-Amplifier with HEOS Built-in Voice Control NEW

13.2ch independent board HDAMR-SA preamplifier

Marantz original current feedback type circuit that realizes overwhelming high slew rate and channel separation.

15.2ch XLR & RCA pre-out

Equipped with 15.2ch pre-out (XLR & RCA) for simultaneous output of up to 13.2ch.

Supports Dolby Atmos, DTS:X Pro, IMAX Enhanced, Auro-3D, MPEG-4 AAC

In addition to new-generation 3D audio, it also supports new 4K/8K satellite broadcast audio formats.

Carefully selected high-quality sound parts suitable for high-end models

Aluminum shield case toroidal transformer, custom block capacitor

Supports 8K/60Hz, 4K/120Hz, HDR10+, HDCP 2.3, eARC

Supports new standards for enjoying the latest video content. HDMI input/output with 8 inputs/3 outputs (8K compatible: 1 input/2 outputs)

HEOS Built-in Enhanced network audio functions

Streaming (Amazon Music HD, AWA, Spotify, etc.), Internet radio, high-resolution file playback.

Wi-Fi, AirPlay 2, Bluetooth and Alexa enabled

Wireless and easy music streaming. It also supports voice control.

Product specifications of Marantz Marantz AV8805A/FB

Others Input sensitivity: Balanced: 400 mV, Unbalanced: 200 mV

S/N ratio: 105 dB (IHF-A, direct mode)

Frequency response: 10 Hz - 100 kHz (+1, -3 dB, in direct mode)

Distortion: 0.005% (20 Hz - 20 kHz, direct mode)

Rated Output: Balanced: 2.4 V, Unbalanced: 1.2 V

HDMI terminal

Input x 8 (8K compatible input x 1, front x 1)

Output x 3 (8K compatible monitor output x 2, Zone 2 x 1)

Video input terminal: component x 3, composite x 5 (front x 1)

Video output terminal: component x 1, composite x 2 (monitor x 1, zone 2 x 1)

Audio input terminal: Balanced (XLR) x 1, Unbalanced (RCA) x 8 (front x 1), Phono (MM) x 1, 7.1ch input x 1, optical digital x 2, coaxial digital x 2

Audio output terminal: 15.2ch balanced pre-out x 1, 15.2ch unbalanced pre-out x 1, zone pre-out x 2, headphones x 1

Other terminals: Network x 1, USB-A (front) x 1, USB-A (rear, power supply dedicated 5 V / 1.5 A) x 1, setup microphone input x 1, Bluetooth/Wi-Fi antenna input x 2, RS-232C x 1, DC trigger output x 2, flasher input x 1, Marantz remote bus (RC-5) input/output x 1

Wireless LAN (network type/frequency): IEEE 802.11 a/b/g/n compliant (Wi-FiR compliant) / 2.4 GHz, 5 GHz

Bluetooth

Version: 4.2

Compatible Profiles: Receiving: A2DP 1.2, AVRCP 1.5

Supported codec: SBC

Transmission output/communication distance: Class 1/about 30 m (line-of-sight distance)

Power supply: *AC 100V, 50/60Hz

Power consumption: 90W

Standby power: 0.2 W (normal standby) / 0.5 W (CEC standby)

Maximum external dimensions

W440 x H185 x D410 mm (with antenna laid down)

W440 x H248 x D410 mm (with antenna up)

Mass: 13.8kg

Accessories: Easy start guide, remote control (RC039SR), AAA batteries x 2, setup microphone, microphone stand, cable label, Bluetooth / Wi-Fi antenna x 2, power cord
