●Audio characteristics

・Rated output: 200 W + 200 W (4 Ω, 1 kHz, T.H.D. 0.1%) 100 W + 100 W (8 Ω, 1 kHz, T.H.D. 0.05%)

・Total harmonic distortion rate: 0.005% (50 W, 8 Ω, 1 kHz)

・Frequency characteristics: 5 Hz ・50 kHz (±3 dB, CD, 1 W, 8 Ω)

・Damping factor: 500 (8 Ω, 20 Hz - 20 kHz)

・Input sensitivity/input impedance: PHONO (MC Low) 250 μV / 33 Ω, PHONO (MC MID) 250 μV / 100 Ω, PHONO (MC HIGH) 250 μV / 390 Ω, PHONO (MM) 2.3 mV / 39 kΩ, CD / LINE 220 mV / 18 kΩ, POWER AMP IN 1.0 V / 18 kΩ

・Output voltage/output impedance: PRE OUT 1.6 V / 220 Ω

・PHONO maximum allowable input: MC 8 mV (1 kHz), MM 80 mV (1 kHz)

・RIAA deviation: ±0.5 dB (20 Hz - 20 kHz)

・S/N ratio (IHF A network, 8Ω): PHONO (MC) 75 dB (0.5 mV input), PHONO (MM) 88 dB (5 mV input), CD / LINE 107 dB (rated output)

●Input/output terminal

・Audio input terminals: unbalanced x 5, PHONO x 1, POWER AMP IN x 1

・Audio output terminal: Pre out x 1, REC out x 1, headphones x 1

・Other input/output terminals: Marantz remote bus (RC-5) input/output x 1

●General

・Power supply: AC 100V, 50/60Hz

・Power consumption: 150W

・Standby power: 0.2 W

・Maximum external dimensions: W443 x H130 x D431 mm

・Mass: 14.6 kg

・Accessories: Easy start guide, instruction manual, remote control (RC002PMND), short plug x 2 (PHONO), AAA batteries x 2, power cord
