This is the successor model of the SL-1200GR, which inherits the technology of the SL-1200G announced in 2016 while bringing together the newly developed technology at the time. Adopts a new generation of motor drive technology, ``ΔΣ (Delta Sigma)-Drive,'' which allows for more precise motor drive. Furthermore, improvements have been made to the power supply circuit, which has a major impact on motor drive.

<Features>

1. New motor drive technology “ΔΣ-Drive” realizes even higher sound quality

Utilizing our unique digital amplifier technology know-how, we have developed a new motor drive technology, ``ΔΣ-Drive.''

Reduces slight uneven rotation and slight vibrations when the motor rotates, achieving stable rotation.

2. Adopts a "Multi-Stage Silent Power Supply" that combines a low-noise switching power supply and a noise removal circuit.

Equipped with a low-noise, low-voltage switching power supply that utilizes the know-how cultivated through the development of fully digital amplifiers.

Adopts "Current Injection Active Noise Cancelling" noise cancellation circuit equivalent to the reference class SL-1000R.

3. High-quality design and environmentally friendly cushioning material following the top model

The design follows the traditional layout of the SL-1200 series, and is available in two colors: silver and black.

Inherits the design of the higher-end model and achieves a higher quality finish.

As part of our efforts to address environmental issues, we have reduced the amount of plastic used in packaging by using cardboard as the cushioning material.

Product Specifications

[General]

Power supply: AC100V, 50/60Hz

Power consumption: 11 W (power on), 0.2 W (power off)

External dimensions (width x height x depth): 453 mm x 173 mm x 372 mm

Mass: approx. 11.5 kg

Allowable operating temperature: 0°C to 40°C

Permissible relative humidity: 35% to 80% RH (non-condensing)

Output terminal: PHONO terminal x 1, PHONO ground terminal x 1

[Turntable section]

Drive method: Direct drive

Drive motor: brushless DC motor

Turntable: Aluminum die-cast (diameter: 332 mm, weight: approx. 2.5 kg (including rubber sheet))

Rotation speed: 33 1/3, 45, 78 rpm

Rotation speed adjustment range (pitch switching): ±8%, ±16%

Starting torque: 2.2 kg･cm

Start-up characteristics: 0.7 s (at 33 1/3 rpm)

Brake mechanism: electronic brake

Wow/Flutter: 0.025% W.R.M.S.

[Tone arm section]

Format: Universal S-shaped tone arm static balance type

Arm effective length: 230 mm

Overhang: 15mm

Tracking error angle: +2° 32′ (30 cm (12 inch) record outer circumference), +0° 32′ (30 cm (12 inch) record inner circumference)

Offset angle: 22°

Arm height adjustment range: 0-6 mm

Needle pressure adjustment range: 0 to 4 g (direct needle pressure reading type)

Shell mass: approx. 7.6 g

Applicable cartridge mass:

(No auxiliary weight)

5.6-12.0 g, 3.1-9.5 g (when using cartridge spacer), 14.3-20.7 g (including head shell)

(When using auxiliary weight)

10.0-16.4 g, 7.5-13.9 g (when using cartridge spacer), 18.7-25.1 g (including head shell)

Cartridge installation dimensions: JIS standard 12.7 mm (1/2 inch) installation interval

Shell terminal lug: 1.2 mmφ 4 pin terminal lug

【accessories】

Turntable sheet x 1, dust cover x 1, EP record adapter x 1, balance weight x 1,

Auxiliary weight x 1, shell x 1, overhang gauge x 1, cartridge mounting screw (1 set),

Cartridge spacer x 1, PHONO cable x 1, PHONO ground wire x 1, power cord x 1
