Supported software:
rekordbox
Serato DJ Pro
Power supply: AC 100V, 50Hz/60Hz
Power consumption: 8W
Standby power consumption (standby state): 0.5 W
Permissible operating temperature: +5°C to +35°C
Permissible operating humidity: 5% to 85% (non-condensing)
Maximum external dimensions (width x depth x height): 453 x 353 x 159 mm
Body mass: 12.2 kg
PHONO output terminal: RCA pin jack: 1 system
USB port: Type-C: 1 system
accessories:
Platter
Platter fixing screw
driver
MAGVEL CLAMP
slip mat
slip sheet
dust cover
balance weight
sub weight
head shell
shell weight
Power cord
Audio cable (integrated ground wire)
USB cable
Quick start guide
Precautions for use
【Turntable】
Drive system: Servo direct drive
Motor: 3-phase brushless DC motor
Brake system: electronic brake
Speed: 33 1/3 rpm, 45 rpm
Speed adjustment range: ± 8 %, ± 16 %, ± 50 %
Wow flutter: 0.15% or less WRMS (JIS WTD)
S/N ratio: 65dB (DIN-B)
Turntable: Aluminum die-cast Diameter: 332 mm
Starting torque:
High: 0.45 N・m (4.5 kgf・cm) or more
Mid: 0.32 N・m (3.2 kgf・cm)
Low: 0.2 N・m (2.0 kgf・cm)
Start-up time: 0.3 seconds (at 33 1/3 rpm)
Brake time:
Max: 3.5s
Mid: 1.0 seconds
Min: 0.5 seconds or less
[Tone arm]
Tonearm type: Universal type S-shaped tonearm, gimbal support type bearing structure, static balance type
Overhang: 15mm
Effective length: 230 mm
Tracking error: within 3°
Arm height adjustment range: 6 mm
Stylus pressure variable range: 0 g to 4.0 g (1 scale 0.1 g)
Appropriate cartridge mass: 2.5 g to 12 g
*Cartridge mass including mounting screws and nuts
With shell weight: 2.5 g to 5.5 g
With balance weights only: 5 g to 9 g
With Subweight: 8.5 g to 12 g
