TASCAM CD-9010CF Professional CD solid state player NEW

Based on the TEAC CD-5010B, the CD-9010CF/CD-9010 is equipped with a tray-type drive that has been specially tuned. Based on long-term interviews with broadcast station operators, we have further tuned the highly durable CD-5010B drive. For the OPEN/CLOSE operation of the CD tray and the DISC LOADING from inserting the disc until it becomes ready to play, we investigated the waiting time allowed at the site and speeded up each operation. The unit of adjustment is actually 0.1 seconds, realizing both durability and operation speed that cannot be achieved with other drives. In addition, it is equipped with a manual eject lever so that it can be switched to a backup system even in an emergency such as a power cutoff. The disc can be ejected manually even when power is not supplied.

Machined aluminum parts boasting excellent strength are used for parts that are likely to collide during movement or operation. In particular, the left and right sides of the remote controller RC-9010D/RC-9010S, which are always exposed, are all aluminum panels.

■ CF compatible

File system: FAT32 (4GB to 32GB), FAT16 (2GB or less)

　Playable formats: BWF, WAV

A group of parts that have been carefully selected after many audition evaluations

In the development of the "CD-9010 system", we not only put together our know-how in the development of commercial audio equipment, but also conducted audition evaluations for the selection of individual parts, and selected parts based on sound quality. Masu. Audition evaluations are conducted in our own audio room, studio, etc.

Equipped with two BurrBrown PCM1796 D/A converters

The D/A converter uses the BurrBrown PCM1796, which is highly rated in audio. Furthermore, in order to optimize the circuit configuration for each LINE OUTPUT and MONITOR OUTPUT, two PCM1796s are installed, one for each output. As a result, high sound quality has been achieved for both outputs, which are operated differently.

Equipped with 9 JRC NJM5532 operational amplifiers with a good reputation for operational amplifiers

The operational amplifier is the JRC NJM5532 operational amplifier, which is also installed in the HS-4000 and is highly rated. This operational amplifier was also selected after many audition evaluations. The CD-9010CF/CD-9010 are equipped with a total of nine NJM5532s.

■ 24-bit processing of 16-bit CD digital audio signals

Internal 24-bit processing is used to achieve high resolution even during low-volume playback. When combined with the RC-9010D/RC-9010S, the 24-bit signal processing achieves high-resolution output even when the faders are turned down.

■ The decoupling capacitor that contributes to the stabilization of the power supply is also carefully selected after audition evaluation.

In audio equipment, a stable power supply is an essential item for achieving high sound quality. As for the decoupling capacitors (bypass capacitors) that supply power to the audio circuit, we conducted numerous listening tests in order to select the decoupling capacitors with the best sound quality.

■ Large-capacity capacitor adoption, power supply unit that achieves both sound quality, high efficiency, and space saving

The power supply unit is equipped with a large-capacity capacitor to supply a stable power supply. As a broadcasting business specification, we have pursued a power supply unit that achieves not only high sound quality but also space-saving and high efficiency.

■ The output terminal adopts NEUTRIK gold-plated connectors that have little deterioration in sound quality over time.

A gold-plated NEUTRIK Canon connector is used, which is resistant to oxidation and maintains high-quality sound even when used for a long period of time.

■Exclusively designed connection cable that achieves both operational efficiency and high sound quality

"CD-9010CF"/"CD-9010" and "RC-9010D"/"RC-9010S" can be connected with only one dedicated cable each, providing excellent operational efficiency even when changing installations or moving locations. Realize Since this cable contains the audio signal for monitoring with the RC-9010D/RC-9010S, there was dissatisfaction with the pursuit of high sound quality with existing cables on the market. Therefore, we have developed a new cable dedicated to connection, and we use a dedicated cable that has a strong shield on the audio line in the connection cable and achieves both sound quality and operational efficiency.

■Size: 220 (width) x 136.8 (height) x 361.5 (depth) mm

■Mass: 5.5kg
