TEAC TN-5BB belt drive analog turntable Black XLR balanced output NEW

TEAC TN-5BB belt drive analog turntable Black XLR balanced output NEW

$1,880.00 USD
$1,880.00 USD
Sale Sold out
Shipping calculated at checkout.
Condition: New Brand: TEAC
Type: Motor Color: Black
Model: TN-5BB-M/B Features: Belt Drive
MPN: TN-5BB-M/B Country/Region of Manufacture: Japan
UPC: Does not apply

Description

Turntable (platter) section
Drive method: Rotation detection type high precision control belt drive
Motor: DC motor
Rotation speed: 33 1/3rpm, 45rpm, 78rpm
Wow/flutter: 0.1% or less
Turntable (platter): Acrylic, diameter 30cm

Cartridge part
Format: MM type
Output voltage: 5.5mV (1kHz, 5cm/sec)
Needle pressure: 1.8g
Cartridge mass: 7.2g
Attached head shell mass: 10g (including screws, nuts, and wires)
Record replacement needle model number: Ortofon replacement needle “stylus 2M Red”
*The lifespan of the needle is approximately 1000 hours, depending on the usage environment.

Tone arm section
Arm type: Static balance S-shaped tone arm
Effective arm length: 223mm
Compatible cartridge weight: 4.0-13g: 14-23g (includes attached head shell)
Overhang: 18mm
Arm height adjustment range: approx. 6mm

general
AC adapter power supply
Input: AC 100V to AC 240V 50-60Hz
Output: DC 12.0V 1.0A 12.0W Max
power consumption
Standby: 0.3W or less
On: 2.0W or less
Mass: approx. 10.5kg
Guaranteed operating temperature: 5°C to 35°C

External dimensions (width, height, depth) (including protrusions)
With dust cover closed: 450 x 148 x 351 mm
With dust cover open: 450 x 420 x 410 mm
With dust cover removed: 450 x 135 x 351 mm
(at upper limit of arm holder)

*Performance data is specified at 20℃.

accessories
Donut disk adapter x 1
Counterweight x 1
Head shell x 1
Already equipped with Ortofon's "2M Red" (MM type)
Turntable (platter) x 1
Flat belt x 1
Pulley cover x 1
Dust cover x 1
Dust cover hinge x 2
Foot height adjustment washers x 4
Hex wrench for arm height adjustment x 1
RCA audio cable x 1
Ground cable x 1
AC adapter (GPE018S-120100-Z) x 1
Cartridge adjustment gauge x 1
Instruction manual (Japanese) x 1
