[Technics' new challenge. A turntable that pursues the sound of a true analog record with the latest direct-drive technology.

◁ENewly developed coreless direct drive motor that realizes stable rotation

The newly developed coreless direct drive motor uses a coreless stator that eliminates the core from the coils that make up the motor. Since no attractive force is generated between the core and the magnet, the magnetic force does not become uneven, and the occurrence of cogging is theoretically eliminated. It achieves about twice the high torque and reduced bearing load compared to the conventional SL-1200MK6. Furthermore, the clearance between the shaft and the bearing, which are the rotating shafts, has been narrowed to the same level as the SP-10MK2 or less to thoroughly reduce minute vibrations during rotation. In addition, high performance can be maintained for a long period of time by adopting oil impregnated bearings. In addition to excellent performance, it is maintenance-free and has reliability that can be used habitually for a long time.

◁EHigh-precision motor control that realizes the optimum rotation state

The latest motor control technology cultivated in the development of Blu-ray Disc equipment is applied to the rotation control of the motor that verifies and corrects the accuracy of rotation, and strong torque and high stability are realized by performing precise switching according to the operating state. Did. Compared to the motor control of SL-1200MK6, the accuracy of the reference clock has been improved by about 3 times, and more accurate rotation control has become possible in combination with accurate rotation position detection.

dimensional accuracy.

[SL-1200G spec]

◁EComprehensive

Power supply: AC 100V 50/60 Hz

Power consumption: 12 W (when power is on) 0.2 W (when power is off)

External dimensions (width x height x depth): 453 x 173 x 372 mm

Mass: Approximately 18.0 kg

Color: -S (silver)

◁ETurntable

Format: Direct drive turntable system (manual)

Drive system: Direct drive

Drive motor: Brushless DC motor

Turntable: Aluminum die-cast / brass integrated type, diameter: 332 mm, mass: approx. 3.6 kg (including rubber sheet)

Rotation speed: 33 1/3, 45, 78 r / min

Rotation speed adjustment range: ± 8%, ± 16%

Starting torque: 3.3 kg �E¥ cm

Start-up characteristics: 0.7 s (at 33 1/3 r / min)

Brake mechanism: Electronic brake

Wow and flutter: 0.025% W.R.M.S. (JIS C5521)

Signal-to-noise ratio (rumble): 78 dB (IEC 98A weighted)

◁ETone arm

Format: Universal S-shaped tone arm Static balance type

Effective arm length: 230 mm

Overhang: 15 mm

Tracking error angle: + 2 ° 32'(30 cm record outer circumference), + 0 ° 32' (30 cm record inner circumference)

Offset angle: 22 °

Arm height adjustment range: 0 to 6 mm

Needle pressure adjustment range: 0 to 4 g (needle pressure direct reading type)

Shell mass: Approximately 7.6 g

Applicable cartridge mass: No auxiliary weight / 5.6 to 12.0 g, 14.3 to 20.7 g (including head shell), when using small auxiliary weight / 10.0 to 16.4 g, 18.7 to 25.1 g (including head shell), when using large auxiliary weight / 14.3-19.8 g, 23.0-28.5 g (including headshell)

Cartridge mounting dimensions: JIS standard 12.7 mm (1/2 inch) mounting interval

Shell terminal lug: 1.2 mmρE4-pin terminal lug

◁EAccessories

Turntable x 1, Turntable sheet x 1, Dust cover x 1, EP record adapter x 1, Balance weight x 1, Auxiliary weight small x 1, Auxiliary weight large x 1, Shell x 1, Overhang gauge x 1, Cartridge mounting screw (1 set) x 1, PHONO cable x 1, PHONO ground wire x 1, power cord x 1, turntable mounting screw (1 set) x 1
