YAMAHA A-S301(S) Integrated Amplifier with DAC Hi-Res Audio silver 100V NEW

●Rated output: 60W + 60W/8Ω (20Hz to 20kHz, 0.019% THD), 70W + 70W/6Ω (20Hz to 20kHz, 0.038% THD)

●Dynamic power (IHF): 100W/8Ω, 120W/6Ω, 140W/4Ω, 150W/2Ω

●"Maximum practical output (JEITA) 100W/8Ω (1kHz, 10% THD), 110W/6Ω (1kHz, 10% THD)

●Output bandwidth: 10Hz to 50kHz (when operating MAIN L/R, 0.04% THD, 30W, 8Ω)

●Damping factor: 210 or more (1kHz, 8Ω)

●Maximum allowable input: PHONO MM: 45mV or more (1kHz 0.03% THD), CD ect: 2.2V or more (1kHz 0.5% THD)

●Rated output voltage/output impedance: REC OUT: 200mV/1.0kΩ or less, Subwoofer OUT: 3.5V/1.2kΩ (cutoff frequency: 100Hz)

●Frequency characteristics: CD etc: 0±0.5dB (20Hz to 20kHz), CD, etc. Pure DIRECTON: 0±1.0dB (10Hz to 100kHz)

●RIAA equalizer deviation: PHONO MM: ±0.5dB

●Total harmonic distortion rate: PHONO MM→REC OUT: 0.03% or less (20Hz to 20kHz 2.5V), CD, etc. → SPOUT: 0.019% or less (20Hz to 20kHz 30W/8Ω)

●S/N ratio (IHF-A network): PHONO MM: 82dB or more (5mV, input shorted), CD, etc.Pure DIRECTON: 99dB or more (200mV, input shorted)

●Residual noise (IHF-A network): 40μV

●Input sensitivity/input impedance: PHONO MM: 3.0mV/47kΩ, CD etc: 200mV/47kΩ

●Headphone rated output: CD etc: 360mV/470Ω (1kHz, 200mV, 8Ω)

●Channel separation: CDetc: 65dB or more (input 5.1kΩ, shorted, 1kHz), CD etc: 50dB or more (input 5.1kΩ, shorted, 10kHz)

●Tone control characteristics: BASS: ±10dB (Boost/Cut 20Hz), 400Hz (turnover frequency) Treble: ±10dB (Boost/Cut 20kHz), 3.5kHz (turnover frequency)

●Input terminals: 8 systems (CD 1, tuner 1, line 3, phono [MM] 1, optical digital 1, coaxial digital 1)

●Output terminals: 5 systems (2 recouts, 1 subwoofer, 1 headphone, 1 CD out)

●Power consumption: 190W

●Standby power: 0.5W

●External dimensions (width x height x depth): 435W x 151H x 387Dmm

●Mass: 9.0kg

●Accessories: Remote control, 3 AA batteries, instruction manual
