YAMAHA A-S501 Pre Main Amp Amplifier Silver Hi-Res DAC 100V NEW
YAMAHA A-S501 Pre Main Amp Amplifier Silver Hi-Res DAC 100V NEW
Regular price
$538.00 USD
Regular price
Sale price
$538.00 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
| Condition: New | Supported Modes: N/A |
| Receiver Combo Features: N/A | Custom Bundle: No |
| Color: Silver | MPN: A-S501(S) |
| Surround Sound Formats: 2 | Audio Outputs: Stereo L/R RCA |
| Number of Outputs: 5 | Brand: YAMAHA |
| Type: Integrated Amplifiers | Unit Type: Unit |
| Audio Inputs: Component | Number of Channels: 2 |
| Number of Inputs: 8 | Model: A-S501(S) |
| Features: High End | Unit Quantity: N/A |
| Country/Region of Manufacture: Unknown | Power: 85W |
| UPC: 4957812573719 |
Description
●Rated output: 85W + 85W/8Ω (20Hz to 20kHz, 0.019% THD), 100W + 100W/6Ω (20Hz to 20kHz, 0.038% THD)
●Dynamic power (IHF): 130W/8Ω, 150W/6Ω, 185W/4Ω, 220W/2Ω
●Maximum practical output (JEITA): 130W/8Ω (1kHz, 10% THD), 150W/6Ω (1kHz, 10% THD)
●Output bandwidth: 10Hz to 50kHz (when operating MAIN L/R, 0.04% THD, 42.5W, 8Ω)
●Damping factor: 240 or more (1kHz, 8Ω)
●Maximum allowable input: PHONO MM: 45mV or more (1kHz 0.03% THD), CD ect: 2.2V or more (1kHz 0.5% THD)
●Rated output voltage/output impedance: REC OUT: 200mV/1.0kΩ or less, SubwooferOUT: 3.5V/1.2kΩ (cutoff frequency: 100Hz)
●Frequency characteristics: CD etc.: 0±0.5dB (20Hz to 20kHz), CD etc.Pure DIRECT ON: 0±1.0dB (10Hz to 100kHz)
●RIAA equalizer deviation: PHONO MM: ±0.5dB
●Total harmonic distortion rate: PHONO MM→REC OUT: 0.03% or less (20Hz to 20kHz 2.5V), CD, etc. → SPOUT: 0.019% or less (20Hz to 20kHz 45W/8Ω)
●S/N ratio (IHF-A network): PHONO MM: 82dB or more (5mV, input shorted), CD, etc.Pure DIRECTON: 99dB or more (200mV, input shorted)
●Residual noise (IHF-A network): 40μV
●Input sensitivity/input impedance: PHONO MM: 3.0mV/47kΩ, CD etc: 200mV/47kΩ
●Headphone rated output: CD etc: 430mV/470Ω (1kHz, 200mV, 8Ω)
●Channel separation: CDetc: 65dB or more (input 5.1kΩ, shorted, 1kHz), CD etc: 50dB or more (input 5.1kΩ, shorted, 10kHz)
●Tone control characteristics: BASS: ±10dB (Boost/Cut 20Hz), 400Hz (turnover frequency) Treble: ±10dB (Boost/Cut 20kHz), 3.5kHz (turnover frequency)
●Input terminals: 8 systems (CD 1, tuner 1, line 3, phono [MM] 1, optical digital 1, coaxial digital 1)
●Output terminals: 5 systems (2 recouts, 1 subwoofer, 1 headphone, 1 DC out)
●Power consumption: 240W
●Standby power: 0.5W
●External dimensions (width x height x depth): 435W x 151H x 387Dmm
●Mass: 10.3kg
●Accessories: Remote control, 2 AA batteries, instruction manual
